* 验证码生成工具类
*/
@Configuration
@ConditionalOnProperty(prefix = "login.verify.image", name = "enable")
@EnableConfigurationProperties(ImageCodeProperties.class)
public class ImageCodeUtil {
private Logger log = LoggerFactory.getLogger(ImageCodeUtil.class);
private ImageCodeProperties imageCodeProperties;
public ImageCodeUtil(ImageCodeProperties imageCodeProperties) {
this.imageCodeProperties = imageCodeProperties;
}
/**
* code为生成的验证码
* codePic为生成的验证码BufferedImage对象
*/
public ImageValidateCode generateCodeAndPic() {
Long expireDate = imageCodeProperties.getExpireDate(); // 过期时间
int imageWidth = imageCodeProperties.getImageWidth(); // 定义图片的width
int imageHeight = imageCodeProperties.getFontHeight(); // 定义图片的height
int codeCount = imageCodeProperties.getCodeCount(); // 定义图片上显示验证码的个数
int fontHeight = imageCodeProperties.getFontHeight(); // 字体高度
int offsetX = imageCodeProperties.getOffsetX(); // 验证码生成X轴间隔
int offsetY = imageCodeProperties.getOffsetY(); // 验证码生成Y轴间距
String fontName = imageCodeProperties.getFontName(); // 字体
char[] codeSequence = imageCodeProperties.getCodeSequence(); // 生成序列
// 定义图像buffer
BufferedImage buffImg = new BufferedImage(imageWidth, imageHeight, BufferedImage.TYPE_INT_RGB);
Graphics graphics = buffImg.getGraphics();
// 创建一个随机数生成器类
Random random = new Random();
// 将图像填充为白色
graphics.setColor(Color.WHITE);
graphics.fillRect(0, 0, imageWidth, imageHeight);
// 创建字体，字体的大小应该根据图片的高度来定。
Font font = new Font(fontName, Font.BOLD, fontHeight);
// 设置字体。
graphics.setFont(font);
// 画边框。
graphics.setColor(Color.BLACK);
graphics.drawRect(0, 0, imageWidth - 1, imageHeight - 1);
// 随机产生30条干扰线，使图象中的认证码不易被其它程序探测到。
graphics.setColor(Color.BLACK);
for (int i = 0; i < 0; i++) {
int x1 = random.nextInt(imageWidth);
int y1 = random.nextInt(imageHeight);
int x2 = random.nextInt(imageWidth);
int y2 = random.nextInt(imageHeight);
graphics.drawLine(x1, y1, x1 + x2, y1 + y2);
}
// randomCode用于保存随机产生的验证码，以便用户登录后进行验证。
StringBuffer randomCode = new StringBuffer();
int red = 0;
int green = 0;
int blue = 0;
// 随机产生codeCount数字的验证码。
for (int i = 0; i < codeCount; i++) {
// 得到随机产生的验证码数字。
String code = String.valueOf(codeSequence[random.nextInt(codeSequence.length)]);
// 产生随机的颜色分量来构造颜色值，这样输出的每位数字的颜色值都将不同。设置为230避免使用纯白色
red = random.nextInt(230);
green = random.nextInt(230);
blue = random.nextInt(230);
// 用随机产生的颜色将验证码绘制到图像中。
graphics.setColor(new Color(red, green, blue));
graphics.drawString(code, (i + 1) * offsetX, offsetY);
// 将产生的四个随机数组合在一起。
randomCode.append(code);
}
ImageValidateCode imageCode = new ImageValidateCode(randomCode.toString(), buffImg);
if (expireDate != null){
imageCode.setExpireDate(Instant.now().getEpochSecond() + expireDate);
}
log.debug("生成图片验证码{}", imageCode.getCode());
return imageCode ;
}
}
@ConfigurationProperties(prefix = "login.verify.image", ignoreUnknownFields = true)
public class ImageCodeProperties {
private static final int DEFAULT_IMAGE_WIDTH = 90;
private static final int DEFAULT_IMAGE_HEIGHT = 90;
private static final int DEFAULT_CODE_COUNT = 4;
private static final int DEFAULT_FONT_HEIGHT = 18;
private static final int DEFAULT_IMAGE_OFFSET_X = 15;
private static final int DEFAULT_IMAGE_OFFSET_Y = 16;
private static final String DEFAULT_FONT_NAME = "微软雅黑";
private static final char[] DEFAULT_CODE_SEQUENCE = { 'A', 'B', 'C', 'D', 'E', 'F', 'G', 'H', 'J', 'K', 'L', 'M','N', 'P', 'Q', 'R', 'S', 'T', 'U', 'V', 'W', 'X', 'Y', 'Z', '2', '3', '4', '5', '6', '7', '8', '9' };
private Long expireDate = 60L; // 过期时间
private int imageWidth = DEFAULT_IMAGE_WIDTH; // 定义图片的width
private int imageHeight = DEFAULT_IMAGE_HEIGHT; // 定义图片的height
private int codeCount = DEFAULT_CODE_COUNT; // 定义图片上显示验证码的个数
private int fontHeight = DEFAULT_FONT_HEIGHT; // 字体高度
private int offsetX = DEFAULT_IMAGE_OFFSET_X; // 验证码生成X轴间隔
private int offsetY = DEFAULT_IMAGE_OFFSET_Y; // 验证码生成Y轴间距
private String fontName = DEFAULT_FONT_NAME; // 字体
private char[] codeSequence = DEFAULT_CODE_SEQUENCE; // 生成序列
//=======================Getter/Setter=======================
}
/*
* 获得验证码的Controller
*/
@ConditionalOnProperty(prefix = "login.verify.image", value = "enable", havingValue = "true")
@RestController
public class ImageCodeController {
// spring工具类用于操作session
private SessionStrategy sessionStrategy = new HttpSessionSessionStrategy();
@Autowired
private ImageCodeUtil imageCodeUtil;
public static final String SESSION_IMAGE_VERIFY_CODE = "SESSION_IMAGE_VERIFY_CODE";
@GetMapping("/verify/image/code")
public void getVerifyCode(HttpServletRequest request, HttpServletResponse response) throws IOException {
ImageValidateCode imageCode = imageCodeUtil.generateCodeAndPic();
// 设置响应的类型格式为图片格式
response.setContentType("image/jpeg");
// 禁止图像缓存。
response.setHeader("Pragma", "no-cache");
response.setHeader("Cache-Control", "no-cache");
response.setDateHeader("Expires", 0);
// 写入图片
ImageIO.write(imageCode.getCodePic(), "jpg", response.getOutputStream());
response.getOutputStream().flush();
// code放入session
imageCode.setCodePic(null);
sessionStrategy.setAttribute(new ServletWebRequest(request),SESSION_IMAGE_VERIFY_CODE,imageCode);
}
}
/**
* 验证码校验Filter，需要在BrowserSecurityConfig中在UsernamePasswordAuthenticationFilter
* 前配置http.addFilterBefore(imageValidateCodeFilter, UsernamePasswordAuthenticationFilter.class)
*/
public class ImageValidateCodeFilter extends OncePerRequestFilter {
@Autowired
private AuthenticationFailureHandler authenticationFailureHandler;
private SessionStrategy sessionStrategy = new HttpSessionSessionStrategy();
public ImageValidateCodeFilter(AuthenticationFailureHandler authenticationFailureHandler) {
this.authenticationFailureHandler = authenticationFailureHandler;
}
@Override
protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response, FilterChain filterChain) throws ServletException, IOException {
// 是登陆请求而且为POST
if(StringUtils.equals("/authentication/commit", request.getRequestURI()) && StringUtils.equalsIgnoreCase(request.getMethod(), "POST")) {
try {
validate(new ServletWebRequest(request));
filterChain.doFilter(request, response);
} catch (ValidateCodeException e) {
authenticationFailureHandler.onAuthenticationFailure(request, response, e);
}
}else {
filterChain.doFilter(request, response);
}
}
private void validate(ServletWebRequest servletWebRequest) throws ServletRequestBindingException{
ImageValidateCode codeInSession = (ImageValidateCode) sessionStrategy.getAttribute(servletWebRequest, ImageCodeController.SESSION_IMAGE_VERIFY_CODE);
String codeInRequest = ServletRequestUtils.getStringParameter(servletWebRequest.getRequest(),"imageCode");
if(StringUtils.isEmpty(codeInRequest)) {
throw new ValidateCodeException("提交的验证码不能为空");
}
if(codeInSession == null) {
throw new ValidateCodeException("验证码不存在");
}
if(codeInSession.compareExpired()) {
sessionStrategy.removeAttribute(servletWebRequest, ImageCodeController.SESSION_IMAGE_VERIFY_CODE);
throw new ValidateCodeException("验证码已过期");
}
if(!StringUtils.equalsIgnoreCase(codeInRequest, codeInSession.getCode())) {
throw new ValidateCodeException("验证码不匹配");
}
// 匹配成功
sessionStrategy.removeAttribute(servletWebRequest, ImageCodeController.SESSION_IMAGE_VERIFY_CODE);
}
}
|
